Beskrivelse
Mercury Marine
87-17393
87-88107
87-88107A5
Back Up Nut: Brass
Face Nut: Hex Black Plastic
Hole Size: 7/8"
Length: Short: 5/8" maximum panel thickness
Material: Marine grade glass-filled Polyester
Rated Choke: 7 Amp @ 12v DC
Rated Ignition: 15 Amp @ 12v DC
Rated Solenoid: 30 Amp @ 12v DC
Terminal Type: 6 Screw Tab
Switch Function: Off - Run - Start
Type: 3 Position Magneto
Push to choke
Maximum corrosion protection - eliminates oxidation
Inner seal between cylinder lock and contact plate
Non-conductive housing eliminates potential shorts
87-17393
87-88107
87-88107A5
Back Up Nut: Brass
Face Nut: Hex Black Plastic
Hole Size: 7/8"
Length: Short: 5/8" maximum panel thickness
Material: Marine grade glass-filled Polyester
Rated Choke: 7 Amp @ 12v DC
Rated Ignition: 15 Amp @ 12v DC
Rated Solenoid: 30 Amp @ 12v DC
Terminal Type: 6 Screw Tab
Switch Function: Off - Run - Start
Type: 3 Position Magneto
Push to choke
Maximum corrosion protection - eliminates oxidation
Inner seal between cylinder lock and contact plate
Non-conductive housing eliminates potential shorts
